109BM12MC2-1
DC Blower Fan – 9BM
● Blows air perpendicular to inlet airflow
● Double ball bearings fan
● Locked rotor burnout protection
● Reverse Polarity Protection
● Frame : Plastic Flammability UL 94V-0
● Impeller : Plastic Flammability UL 94V-0
-
Product category
-
Partner name
-
Series name
Attributes
Fan Type
BlowerSize (mm)
97x33Supply Voltage
12VDCSensor Type
With Pulse Sensor
| Fan Type | Blower | Size | 97×33 | Supply Voltage | 12VDC |
| Sensor Type | Without Sensor | Max. Airflow – m3/min | 0.58 | Max. Airflow – CFM | 20.5 |
| Max. Static Pressure – Pa | 119 | Max. Static Pressure – inch H2O |
0.478 | RPM | 2700 |
| Noise Level – dB(A) | 43.5 | Operating Temperature | -20 to +70 | Rated Current | 0.26 |
Blower 97*33mm , 12DC, 0.26 A,Max. Airflow 0.58 m3/min or 20.5 CFM, Max. Static Pressure 119 Pa or 0.478 inchH2o, RPM 2700, 43.5 dB, 3 wire, with Pulse sensor, 40000/60? (70000/40?), -20 to +70 °C
