16-IN PNP(P372)
16-IN PNP module
● 24Vdc sourcing (PNP)
● 16 Input channels
● RC network 18KHz
● Input current 3.5mA
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Controller Type
I/O ExpansionsControl Mode
EtherCATCommunication
EtherCAT
| Max. Interface per MC664/MC664X | N.A. | Max. Axis on MC664/MC664X | N.A. | Max. Axis per Interface | N.A. |
| Max. Axis | N.A. | Pulse-Dir. Axis | N.A. | AS Axis | N.A. |
| Encoder Axis | N.A. | Extended Axis | N.A. | Digital I/O | 16 IP |
| Analogue I/O | N.A. | Serial Port | N.A. | Ethernet Port | N.A. |
| EtherCAT Port | 1 | CANopen Port | N.A. | RTEX Port | N.A. |
| SERCOS II Port | N.A. | SLM Port | N.A. | Power Supply | 24V DC |
| Programming | N.A. | Processor | N.A. | Servo Update | N.A. |
| Motion Commands | N.A. | Network Speed | 100Mbit/sec | Refresh Rate | >=125uS |
| Certification | RoHS, UL & CE |
16-IN PNP module has 24Vdc sinking (PNP) type 16 input channels. It has a 3.5mA/channel input capacity. RC network 18KHz. Network speed 100mbps and refresh rate >=125us. ON voltage 11.2V and OFF voltage 10.2V threshold level. RoHS, UL, and CE approved.
