3D-A5005-2031-H
IN-SIGHT A5000 3D VISION SYSTEM
● Clearance distance: 299.3 mm
● Measurement range: 12.0 mm
● Near end FOV: 60 x 44 mm
● Far end FOV: 65 x 46 mm
● No. of 3D points: > 1.5 million
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Vision Type
3D Vision SystemResolution
NAImage Sensor
MonochromeLens
-NA-Lens Type
NA
| Clearance Distance (CD) | 299.3 mm | Measurement Range (MR) |
12 mm | Near FOV | 60 x 44 mm |
| Far FOV | 65 x 46 mm | Resolution Z | 7–8 μm | Resolution XY | 42–44 μm |
| Acquisition Time | 200 msec | Software | VisionPro | Ethernet | 10 Gigabit Ethernet interface |
| Power | 24 VDC±10%, | Material | Aluminum | Protection | IP65 |
High-Resolution Area Scan 3D Camera Head Cognex’s 3D-A5000 series is a factory-calibrated, IP65-rated area scan 3D camera designed to capture high-resolution 3D images. The 3D-A5000 features patent-pending 3D LightBurst™ technology which rapidly acquires images to maximize throughput. High-resolution 3D images combined with industry-leading Cognex 3D vision tools enable reliable and accurate solutions to applications such as assembly verification, in-line measurement, and robotic guidance
