3D-A5120-2101-H

 IN-SIGHT A5000 3D VISION SYSTEM

 ● Clearance distance: 1000 mm

 ● Measurement range: 1000 mm

 ● Near end FOV: 900 x 675 mm

 ● Far end FOV: 1760 x 1320 mm

 ● No. of 3D points: > 1.5 million

Attributes

  • Vision Type

    3D Vision System
  • Resolution

    NA
  • Image Sensor

    Monochrome
  • Lens

    -NA-
  • Lens Type

    NA
SKU: 3D-A5120-2101-H Category:
Clearance Distance (CD) 1000 mm Measurement
Range (MR)
1000 mm Near FOV 900 x 675 mm
Far FOV 1760 x 1320 mm Resolution Z 414–1656 μm Resolution XY 626–1223 μm
Acquisition Time 200 msec Software VisionPro Ethernet 10 Gigabit Ethernet interface
Power 24 VDC±10%, Material Aluminum Protection IP65

High-Resolution Area Scan 3D Camera Head Cognex’s 3D-A5000 series is a factory-calibrated, IP65-rated area scan 3D camera designed to capture high-resolution 3D images. The 3D-A5000 features patent-pending 3D LightBurst™ technology which rapidly acquires images to maximize throughput. High-resolution 3D images combined with industry-leading Cognex 3D vision tools enable reliable and accurate solutions to applications such as assembly verification, in-line measurement, and robotic guidance

Download Datasheet
Download Catalogue
