AIMB-707
Intel® 10th generation Core™ i9/i7/i5/i3
● Pentium®/Celeron® processor with H420E chipset
● Dual-channel (Non-ECC) DDR4 2400/2666/2933 up to 64 GB
● Support VGA and DVI display
● M.2, SATA 3.0, USB 3.2, dual GbEs 5 RS-232 and 1 RS-232/422/485 serial ports
● 1 PCIe x16 (Gen 3) and 2 PCIe x4 (x1 Gen 3 link), and 4 PCI expansion slots
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Type
Industrial Board3rd Generation
No4th Generation
No6th Generation
No7th Generation
No8th Generation
No9th Generation
No10th Generation
YesXeon Processor
NoRAID Support
No
| Form Factor | ATX Motherboard | Processor | i9-10900K, i9-10900E, i9-10900TE, i7-10700E, i7-10700TE, i5-10500E, i5-10500TE, i3-10100E,i3-10100TE G6400E, G6400TE, G5900E, G5900TE |
RAID Support | No |
| RAM | Max CapTechnology Dual Channel(Non-ECC) DDR4 2400/2666/2933 Max Capacity 64 GB Sockets 2 x 288-pin DIMMacity 64 GB |
SATA | Max Data Transfer Rate 600 MB/s Channel 4 |
Expansion Slot | PCI 4 (32-bit/33 MHz) PCIe x4 (Gen 3) 2 (link x1), PCIe x16 (Gen 3) 1 |
| I/O | VGA 1 (Resolution up to 1920 x 1200 @ 60 Hz) DVI 1 for G2 version (Resolution up to 1920 x 1200 @ 60 Hz) Ethernet 2 for G2 version; 1 for VG version USB 6 (USB 3.2 Gen 1 for G2 version; 4 for VG version) Audio 2 (Line-out, Mic-in), Serial 2 (RS-232) |
Network | Interface 10/100/1000 Mbps Controller GbE LAN1: Intel I219-V, GbE LAN2: Intel I211-AT Connector 2 x RJ-45 |
Display Port | VGA 1 DVI 1 for G2 version |
| Max Resolution | (Resolution up to 1920 x 1200 @ 60 Hz) | Graphics | Intel® HD Graphics | Watchdog Timer | Programmable 1 ~ 255 sec |
With ATX form factor, Advantech AIMB Series are well-accepted motherboards offering the most expansion capability for industrial applications. AIMB-707 motherboard is LGA1200 10th Generation Intel® Core™ i9/i7/i5/i3 & Pentium®/Celeron® ATX with DVI/VGA, DDR4, USB 3.2, M.2, 6 COMs
