AIMB-786
Intel® 8th/9th generation Core™ i7/i5/i3/Pentium®/Celeron® processor with Q370chipset
● Four DIMM sockets up to 128 GB DDR4 2400/2666
● Triple display VGA/DVI-D/DP and dual GbE LAN
● SATA RAID 0, 1, 5, 10, USB 3.1
● Supports Intel vPro, AMT & TPM technologies
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Type
Industrial Board3rd Generation
No4th Generation
No6th Generation
No7th Generation
No8th Generation
Yes9th Generation
Yes10th Generation
NoXeon Processor
NoRAID Support
Yes
| Form Factor | ATX Motherboard | Processor | i7-9700E, i7-9700TE, i7-8700, i7-8700T, i5-9500E, i5-9500TE, i5-8500, i5-8500T, i3-9100E, i3-9100TE, i3-8100, i3-8100T, G5400, G5400T, G4900, G4900T |
RAID Support | SATA RAID 0, 1, 5, 10 |
| RAM | Max. Capacity 128 GB | SATA | Max Data Transfer Rate 600 MB/s Channel 5 |
Expansion Slot | PCI 32-bit/33 MHz, 2 slots PCIe x4 (Gen 3) 4 GB/s per direction, 4 slots PCIe x16 (Gen 3) 16 GB/s per direction, 1 slot |
| I/O | VGA 1 (Resolution up to 1920 x 1200 @ 60 Hz) DVI-D 1 (Resolution up to 1920 x 1200 @ 60 Hz) DisplayPort 1 (Resolution up to 4096 x 2304 @ 60 Hz) Ethernet 2, USB 8 (2 x USB 3.1 Gen 2, 2 x USB 3.1 Gen 1, 4 x USB 2.0), Audio 2 (Line-out, Mic-in) |
Network | Interface 10/100/1000 Mbps Controller GbE LAN1: Intel I219-LM, GbE LAN2: Intel I211-AT Connector 2 x RJ-45 |
Display Port | VGA 1 (Resolution up to 1920 x 1200 @ 60 Hz) DVI-D 1 (Resolution up to 1920 x 1200 @ 60 Hz) DisplayPort 1 (Resolution up to 4096 x 2304 @ 60 Hz) |
| Max Resolution | VGA 1 (Resolution up to 1920 x 1200 @ 60 Hz) DVI-D 1 (Resolution up to 1920 x 1200 @ 60 Hz) DisplayPort 1 (Resolution up to 4096 x 2304 @ 60 Hz) |
Graphics | Intel® HD Graphics | Watchdog Timer | Programmable 1 ~ 255 sec |
With ATX form factor, Advantech AIMB Series are well-accepted motherboards offering the most expansion capability for industrial applications. AIMB-786 motherboard is LGA1151 8th/9th Generation Intel® Core™ i7/i5/i3/Pentium®/Celeron® ATX with Triple Display, DDR4, USB 3.1, SATA 3.0
