AWK-4131A-EU-T
Outdoor industrial IEEE 802.11a/b/g/n wireless AP/bridge/client
● 2×2 MIMO 802.11a/b/g/n AP/bridge/client
● Millisecond-level Client-based Turbo Roaming
● Easy setup and deployment with AeroMag
● Wireless redundancy with AeroLink Protection
● Easy network setup with Network Address Translation (NAT)
● Avoid wireless congestion with 5 GHz DFS channel support
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
WLAN Type
AP/bridge/client
| Device Type | WLAN APBridgeClient | WLAN Operation Mode | Access point, Client, Client-Router, Master, Slave, Sniffer |
WLAN Standards | 802.11a/b/g/n 802.11i Wireless Security |
| Ethernet Port | 1 PoE Ports (10/100/1000BaseT(X), RJ45 connector) |
Serial Port | 1 RS-232, 8-pin RJ45 | Input Voltage | 12 to 48 VDC, Redundant dual inputs, 48 VDC Power-over-Ethernet |
| IP | IP68 | Mounting | Wall mounting (standard), DIN-rail mounting (optional), Pole mounting (optional) |
Dimensions | 224 x 147.7 x 66.5 mm (8.82 x 5.82 x 2.62 in) |
| Weight | 1,400 g | Housing | Metal | Operating Temperature | -40 to 75°C (-40 to 167°F) |
| Warranty Period | 5 years |
The AWK-4131A IP68 outdoor industrial AP/bridge/client meets the growing need for faster data transmission speeds by supporting 802.11n technology and allowing 2X2 MIMO communication with a net data rate of up to 300 Mbps. The AWK-4131A is compliant with industrial standards and approvals covering operating temperature, power input voltage, surge, ESD, and vibration. The two redundant DC power inputs increase the reliability of the power supply, and the AWK-4131A can be powered via PoE to make deployment easier
● IP68-rated weatherproof housing designed for outdoor applications and -40 to 75°C wide operating temperature range
● Rugged industrial design with integrated antenna and power isolation
