DMR-72Q-0530
DataMan 72Q Extended Range ID Reader
● 1-D & 2-D Code Reading
● 1DMax+™ with Hotbars™
● Up to 45 decodes per second
● 16mm Manual Focus lens
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Code Reader Type
Fixded MountResolution
1.2MPCommunication
USBLens
16 mmLens Type
Fixed Focus
| Algorithms | 1DMax, Hotbars, IDQuick | Image Resolution | 1280 x 960 global shutter | Maximum Acquisition Speed | 60 fps |
| Max Decode Rate | 45/second | Lens | 16 mm manual focus lens | Discrete Inputs | 1 Trigger(Optional) |
| Discrete Outputs | 1 Output (Optional) | Lighting | 4 high-power LEDs | Communications Protocols | Integrated USB-C |
| Power | 5 VDC–24 VDC or USB Bus powered, 2.5W |
Material | Plastic (polycarbonate) | Protection | IP65 |
● 1280 x 960 resolution
● 16mm Manual Focus lens
● Metal front cover with HPIL, Red LEDs
● Integrated USB-C, Optional serial communication with accessory
● Compact design for small space mounting: 22.2mm (H) x 53.7mm (L) x 42.4 (W)
● IP65 Rated with IP65 Cable
