DP-102

Dual Display Digital Pressure Sensor [For Gas]

 ● Pressure Range : -0.1 to +1.000 MPa

 ● Pressure Port : M5 Female Thread + R1/8 male Thread

 ● Output : 2 x NPN

 ● Connector Type

Attributes

  • Type

    Gauge Pressure (For Gas)
  • Shape

    Square
  • Applicable fluid

    Non-corrosive gas
  • Pressure Range

    -0.1 to +1.000 MPa
  • Pressure Port

    M5 Female Thread + R1/8 male Thread
  • Output

    2 x NPN
Type Gauge Pressure (For Gas) Shape Square Applicable fluid Non-corrosive gas
Pressure Range -0.1 to +1.000 MPa Pressure with standability 1.5 MPa Pressure Port M5 Female Thread + R1/8 male Thread
Selectable Unit MPa, kPa, kgf/cm2, bar, psi Digital Display Yes Output 2 X NPN
Output Operation NO / NC Selectable Input supply 12 to 24 VDC Connection Type Connector Type
Response Time 2.5 ms Enclosure PBT Protection
Particular Characteristics 4 digits + 4 digits 3-color LCD Display

Improvements to the digital display deliver a wide viewing angle along with increased clarity. The display pressure range and set pressure range have also been increased. Enhanced power circuitry Addition of a reverse polarity protection circuit to the transistor output circuit. Equipped with a 30 mm 1.181 in square compact-sized dual display. The current value and the threshold value can be checked at the same time, so the threshold value can be set and checked smoothly without switching to another screen mode. ON / OFF operations still continue while the threshold values are being set, so setting to the same sensitivity as dial control-type sensors is possible. Key lock function is equipped as well. The main display changes color in line with changes in the status of output ON / OFF operation, and it also changes color while setting is in progress. The sensor status can therefore be understood easily, and operating errors can be reduced. Three output modes are suitable for a wide range of applications
Equipped with two independent comparative outputs, and separate sensing modes can be selected for each of them. Since there are two comparative outputs, one of the comparative outputs can even be used for alarm output. In addition, output, which is not being used, can be disabled.
