DVP12SA211T
Advanced model supporting 2-axis interpolation
● 32-bit CPU for high-speed processing
● Program capacity: 16 k steps
● Data register: 10 k words
● Max. execution speed of basic instructions: 0.35 μs
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
PLC Module
CPUI/O Selection
Mix DI/DOSupply
24VDCOutput Type
TransistorIn Built
NO
| Type | CPU | Input/Output | Mix DI/DO | Ethernet | NO |
| Output Type | Transistor | HSC | 100KHz*3 | PTO | 100KHz*2 |
| Resolution | N.A. |
DVP-SA2 is a 12-point (8DI + 4DO) PLC MPU, offering various instructions and with 16k steps program memory, able to connect to all DVP-S series extension modules and high-speed extension modules, including digital I/O (max. 480 I/O points) and analog modules (for A/D, D/A conversion, and temperature measurement). 2 points of 100 kHz and 2 points of 10 kHz high-speed pulse output satisfy all kinds of applications. DVP-SA2 is small in size and easy to install. Users do not have to install any batteries in DVP-SA2 series PLCs. The PLC programs and the latched data are stored in high-speed flash memories.
