EX-L262-P
Amplifier Built-in Ultra-Compact Laser Sensor
● Diffuse Type (Convergent Reflective),
● Line Beam Type
● Sensing Range : 20 to 70 mm,
● Output : PNP,
● Fixed Cable 2m,
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Sensor Type
Laser Sensor (Amplifier Built-in)Type
DiffuseShape
RectangularSensing Range
20 to 70 mmOutput
PNPConnection Type
Fixed Cable, 2m
| Type | Diffuse | Shape | Rectangular | Sensing Range | 20 to 70 mm |
| Repeatability | – | Digital Dispaly | – | Output | PNP |
| Output Operation | L-ON / D-ON Selectable |
Input supply | 12 to 24 VDC | Emitting Element | Red Semiconductor Laser Class 1 |
| Connection Type | Fixed Cable, 2m | Sensing Object Size | – | Beam Spot Diameter | 5 x 1 mm at 50 mm |
| Timer Function | – | Response Time | < 0.5 ms | Enclosure | Polybutylene terephthalate |
| Protection | IP67 (IEC) | Particular Characteristics | Line Beam Type |
Due to the customized IC and optical design, high precision detection is fulfilled with directivity and visibility achievable only by laser. The laser adopted is Class 1 (IEC / JIS / FDA / GB) laser that is safe to use, so that there is no need to separate the areas of sensor usage. Light aberrations are reduced and a high definition laser spot is possible by incorporating a molded aspheric glass lens. Due to convergent distance sensing, the background has very little effect, enabling stable sensing. Sensitivity adjuster allows you to adjust sensitivity to avoid sensing background objects when the distance between the workpiece and background objects is small. Able to reliably sense unevenly-colored workpieces. The sensor can be used even in environment where water or dust present because of its protection structure IP67
