Intel® Atom™ E3845 1U Fanless System 1.91 GHz

 ● EN 50121-4 Compliant for Railway Applications

 ● 4 GB of DDR3 memory onboard

 ● GbE and 10 x RS-232/422/485 ports with isolation design

 ● 6 x USB 2.0 and 1 x USB 3.0 slots

 ● 1 x VGA and 1 x DVI D display outputs


  • Type

    Wayside controller
Cooling Fanless PC Processor Intel® Atom™ E3845
quad-core processor,
1.91 GHz
RAID Support NO
RAM Dual-channel DDR3 1333 Max.
Capacity Onboard 4 GB
(up to 8 GB with SODIMM)
Storage SSD 1 x mSATA socket
(optional with SATA2)
HDD 1 x 3.5″ or 2 x 2.5″ HDD bay
Expansion Slot PCI104 1
Mini PCIe 1
I/O USB 6 x USB 2.0,1 x USB 3.0
Serial 2 x DB9(RS-232/422/485) &

8 x RS-232/422/485 with
2 x 20-pin terminal block

Network 4 x RJ45 10/100/1000 Mbps Display Port VGA x 1
DVI-D x 1
Max Resolution 1920 x 1080 Mounting 1U Rackmount Power Supply

Wayside controller series provide various applications such as communication-based train control, wayside signaling and train control system. Our wayside controller system includes CTC and ATC systems that is responsible for collecting and displaying current status of all operating stock, railways, and stations, distributing back-up equipment or power for emergency situations, and connecting the interfaces and structures of sub-systems, such as Interlocking
