ITA-5231

 Intel® 6th Generation Core™ i Processor Fanless System

 ● Intel skylake-H platform with QM170 Fanless computer

 ● EN 50155 Compliant for Railway Applications

 ● Compliant with EN 50121-3-2/ EN 50121-4 EMC test standard

 ● Ruggedized connectors (M12) used for communication and power ports

 ● No RED Certification

Attributes

  • Type

    Rolling stock controller
Cooling Fanless PC Processor Intel® 6th Generation Core™ i RAID Support Yes
RAM 8GB on board memory,
DDR4 2133MHz
SODIMM slot 1 with
Max. Capacity Up to 16GB
Storage HDD/SSD easy-swap
module 4 x 2.5" SSD/HDD
(15mm) with key latch design,
supports RAID 0,1,5,10
mSATA 1 x mSATA slot on board
Expansion Slot Mini PCIe 3 x Mini
PCIe Socket (full size)
SIM card 2 x SIM slot
I/O 2 x USB3.0 with Type A
1 x USB2.0 with
M12 A-coded(F) 4-pin
Serial Port 2 x DB9,
RS-232/422/485 with 2KV
Isolation, supports auto-flow control
Network 3 x RJ45, 10/100/1000 Mbps Display Port Main Display
1 x DVI-I (optional to DVI-
D+VGA via Y cable)
Max Resolution 1920×1200 Mounting Rack-mounting Power Supply 24 V DC

Rolling stock controller caters to rolling stock’s application include Passenger Information system, VehicleMonitoring System and more. The ITA-5000 series of industrial grade modular box PCs exclusively designed for rolling stock solutions. Rolling stock applications include On-board CCTV/NVR surveillance systems, Passenger Information System (PIS), and vehicle monitoring systems. Rolling stock controller series feature shock and vibration resistance during railway operation
