LRE05
EasyPact TVS differential thermal overload relay
✔ Thermal protection adjustment range:- 0.63…1 A
✔ Thermal overload class:- class 10A
✔ EasyPact TVS thermal overload relays are designed to protect a.c. circuits
-
Product category
-
Partner name
-
Series name
Attributes
Thermal Protection Range
0.63 to 1
| Thermal protection adjustment range | 0.63…1 A | Product compatibility | LC1E06…38 | auxiliary contact composition | 1 NO + 1 NC |
| Mounting support | Under contactor Plate, with specific accessories Rail, with specific accessories |
Relay application | Motor protection | Network frequency | 50…60 Hz |
| signalling function | Relay trip indicator | Thermal overload class | Class 10A conforming to IEC 60947-4-1 | Start-up Torque | – |
| Rated Operational Voltage | [Ue] rated operational voltage:- <= 690 V AC |
✔ EasyPact TVS differential thermal overload relay 0.63…1A – class 10A
✔ Conformance to IEC 60947-4-1, CE Marking
✔ Range : 0.1A to 630A
✔ Tripping Class : 10A Direct & Independent mounting
✔ Mounting support:- Under contactor Plate, with specific accessories Rail, with specific accessories
✔ Signalling function:- Relay trip indicator
✔ EasyPact TVS thermal overload relays are designed to protect a.c. circuits and motors against:
1) overloads
2) phase failure
3) Long starting time
4) prolonged stalled rotor condition
