MC404Z(P855)
Advanced 4 Axis Stepper controller
● Inbuilt 16/8 Digital I/O, 1/1 Analogue I/O.
● Incremental Encoder interface.
● Serial, Trio ActiveX, Ethernet Interface Built-in.
● Flexible CAM, Linked Motion, Interpolation, and Robotic Transformations.
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Controller Type
Motion CPUControl Mode
Pulse DirectionCommunication
N.A.
| Max. Interface per MC664/MC664X | N.A. | Max. Axis on MC664/MC664X | N.A. | Max. Axis per Interface | N.A. |
| Max. Axis | 4 | Pulse-Dir. Axis | 4 | AS Axis | N.A. |
| Encoder Axis | 1 | Extended Axis | N.A. | Digital I/O | 16-DI 24 PNP/NPN 8-DO 24V NPN |
| Analogue I/O | 1-AI +/-10VDC 1-AO +/-10VDC |
Serial Port | 1 | Ethernet Port | 1 |
| EtherCAT Port | N.A. | CANopen Port | 1 | RTEX Port | N.A. |
| SERCOS II Port | N.A. | SLM Port | N.A. | Power Supply | 24V DC |
| Programming | Trio BASIC IEC 61131-3 | Processor | 528MHz ARM Cortex M7 |
Servo Update | 125 to 2000μSec |
| Motion Commands | Flexible CAM, Linked Motion, Linear, Circular, Helical & Spherical Interpolation. |
Network Speed | N.A. | Refresh Rate | N.A. |
| Certification | RoHS, UL & CE |
Advanced 4-Axis Stepper controller. Inbuilt Digital I/O, Analogue I/O, Micro SD card slot. Incremental Encoder interface. Ethernet-IP, Modbus TCP, Modbus Serial, Trio ActiveX, Ethernet Interface Built-in. 500-2000 micro sec. Selectable Servo Update. 528MHz ARM Cortex M7 Processor. Multi-tasking BASIC and IEC 61131-3 Programming. Flexible CAM, Linked Motion, Interpolation, and Robotic Transformations. Hardware Linked Outputs for Camera/Laser control & Text File Handling. RoHS, UL, and CE approved.
