MC664(P861)

 Advanced 2 to 64 Axis Moton controller CPU

 ● Expansion module available for EtherCAT, RTEX, Sercos II, SLM Digital drive interface, and Anybus CC module support.

 ● Inbuilt 8/8 Digital I/O, 2 Analogue I/P.

 ● Incremental or Absolute Encoder interface.

 ● Serial, Trio ActiveX, Ethernet Interface Built-in.

 ● Flexible CAM, Linked Motion, Interpolation, and Robotic Transformations.

Attributes

  • Controller Type

    Motion CPU
  • Control Mode

    EtherCAT
  • Communication

    EtherCAT
SKU: MC664(P861) Category:
Max. Interface per MC664/MC664X N.A. Max. Axis on MC664/MC664X N.A. Max. Axis per Interface N.A.
Max. Axis 64 Pulse-Dir. Axis 1 AS Axis N.A.
Encoder Axis 1 Extended Axis 1 Digital I/O 8-DI 24V PNP
8-Bidirectional IO
24V PNP
Analogue I/O 2-AI +/-10VDC Serial Port 1 Ethernet Port 1
EtherCAT Port N.A. CANopen Port 1 RTEX Port N.A.
SERCOS II Port N.A. SLM Port N.A. Power Supply 24V DC
Programming Trio BASIC IEC 61131-3 Processor Single Core Cortex A9
1GHz Processor
Servo Update 125 to 2000μSec
Motion Commands Flexible CAM, Linked Motion,
Linear, Circular,
Helical & Spherical Interpolation.
Network Speed N.A. Refresh Rate N.A.
Certification RoHS, UL & CE

Up to 64 Axes / 64 Stepper / Servo Axes and 64 Virtual Axes controller. EtherCAT, SERCOS, SLM, RTEX digital drive interface. Inbuilt 8-I/P, 8-Bidirectional I/O, micro SD card slot. Isolated Encoder Port supports Incremental or EnDAT, SSI, Tamagawa Absolute Encoder. Ethernet-IP, Modbus TCP, Modbus Serial, Trio ActiveX, Ethernet Interface Built-in. 125-2000 micro sec. Selectable Servo Update. Single Core Processor. Flexible CAM, Linked Motion, Interpolation, and Robotic Transformations. Supports Position Speed and Torque Drive Modes. Hardware Linked Outputs for Camera/Laser control & Text File Handling RoHS 2, UL and CE approved.
