MGate 5114-T
1-port Modbus RTU/ASCII/TCP/IEC 101-to-IEC 104 gateways
● Protocol conversion between Modbus RTU/ASCII/TCP, IEC 60870-5-101, and IEC 60870-5-104
● Supports IEC 60870-5-101 master/slave (balanced/unbalanced)
● Supports IEC 60870-5-104 client/server
● Supports Modbus RTU/ASCII/TCP master/client and slave/server
● Effortless configuration via web-based wizard
● Status monitoring and fault protection for easy maintenance
● Security features based on IEC 62443
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Protocol Device 1
Modbus RTU/ASCII/TCP/IEC 101Protocol Device 2
IEC 104 gateways
| Converter Type | Modbus TCP Gateway | Protocol from | Modbus RTU/ASCII/ TCP/IEC 101 |
Protocol to | IEC 104 gateways |
| Ethernet Port | 2 PORT 10/100BaseT(X) Ports (RJ45connector) |
Serial Port | 1 RS-232/422/485 | Input Voltage | 12 to 48 VDC |
| IP | IP30 | Mounting | – | Dimensions | 36 x 105 x 140 mm (1.42 x 4.14 x 5.51in) |
| Weight | 507 g (1.12 lb) | Housing | Metal | Operating Temperature | -40 to 75°C (-40 to 167°F) |
| Warranty Period | 5 years |
The MGate 5114 is an industrial Ethernet gateway with 2 Ethernet ports and 1 RS-232/422/485 serial port for Modbus RTU/ASCII/TCP, IEC 60870-5-101, and IEC 60870-5-104 network communications. By integrating commonly used power protocols, the MGate 5114 provides the flexibility needed to fulfill the various conditions that arise with field devices that use different communications protocols to connect to a power SCADA system. To integrate Modbus or IEC 60870-5-101 devices onto an IEC 60870-5-104 network, use the MGate 5114 as a Modbus master/client or IEC 60870-5-101 master to collect data and exchange data with IEC 60870-5-104 systems
● Embedded traffic monitoring/diagnostic information for easy troubleshooting
● microSD card for configuration backup/duplication and event logs
● Built-in Ethernet cascading for easy wiring
● Redundant dual DC power inputs and relay output
● -40 to 75°C wide operating temperature models available
● Serial port with 2 kV isolation protection
