VRS-060B-10-K3-14BD19
Compact and precise Gear box
● Carburized helical gears with proprietary secondary finishing
● 40% higher tooth surface area than the industry standard
● One piece output shaft and planet carrier with two bearings
● Higher stiffness, torque capacity and safety factor
● Uncaged needle roller bearings provide excellent torque density and torsional rigidity
-
Product category
-
Partner name
-
Series name
Attributes
Backlash
3 ARC MINMounting
INLINE
| W Number (kw) | – | Ratio | 10 | Rated Output Speed(r.p.m.) | 3000 |
| Backlash(arc.min.) | less than 3 | Noise level [db] | less than 66 | Torsional Regidity(Nm/arc.min.) | 3 |
| efficiency (%) | 95 |
The VRS is the ideal solution for demanding positioning accuracy and speed requirements. This product is a proven performer in higher speed, continuous duty applications where heat reduction is critical. Equipped with two rows of robust tapered roller bearings, the VRS runs smoothly and quietly even with the most challenging dynamic and static forces
The VRS is available with reduced backlash, less than 2 arc-min, to handle dynamic machine tool and robotic applications with ease. With maximum acceleration torques up to 3700Nm, this product is an excellent partner to higher capacity servomotor models. Our customers specify this product when the industry standard is simply not good enough
