ECU-4574

 Intel® Atom™ N2600 Power & Energy Computers

 ● IEC 61850-3 and IEEE 1613 compliant for substation applications Intel Atom N2600 1.6GHz processor, 2GB DDR3

 ● 2 x RS-232, 8 x RS-232/485 isolated serial ports

 ● 2 x 10/100/1000, 6 x 10/100 Base-T Ethernet ports

 ● 1 x CF, 1 x 2.5″ SATA SSD

 ● Redundant isolated power with wide AC/DC input range

Attributes

  • Type

    Rackmountable Fanless Box PCs (ECU-4000 Series)
Type Power & Energy Computers Serial Port 2 x RS-232, 8 x RS-232/485
(RS-422 is project based support)
2,500 VDC isolation
Ethernet Port 2 x 10/100/1000
Base-T RJ-45 ports
Communication Protocol NA Mounting 1U Rack-mount Power Supply 100 ~ 240 VAC
or 100 ~ 240 VDC

The ECU-4574 product is compliant with Electricity Certificate level IV, IEC 61850-3 and IEEE 1613 certification, provides higher reliability and stability performance that is suitable for global smart substations. With a flexible communication interface, the ECU-4574 works as an IED Analyzer that fulfills the smart substation bay level requirements. Featuring a fanless design with Intel Atom N2600 processor, 10 isolated serial ports, eight Ethernet ports, the ECU-4574 is easy for customization and fast assembly to fulfill different kinds of applications

Download Datasheet
Download Catalogue
