EKI-2525

 5FE Unmanaged Ethernet Switch

 ● Provides 5 Fast Ethernet ports with Auto MDI/MDI-X

 ● Supports 10/100 Mbps Auto-Negotiation

 ● Provides compact size with DIN-rail/Wall mount, and IP30 metal mechanism

 ● Supports redundant 12 ~ 48 VDC

 ● Power input and P-Fail relay

Attributes

  • Type

    Unmanaged
  • Fast Ethernet

    Yes
  • Giga Ethernet

    No
  • Fiber Port

    No
Type Unmanaged Ethernet Switches ƒ LAN 5 x 10/100Base-T(X) Optical Fiber NA
Connectors 5 x RJ-45 Transmission Distance 100 m Transmission Speed 10/100 Mbps
Standard 802.3, 802.3u, 802.3x LED Indicators P1, P2, P-Fail
10/100T (X): Link/Activity, Duplex/Collision
Protocol Support NA
Switch Properties NA Power Supply Redundant 24V DC Certification Safety:-UL 62368
ƒ EMI:- CE, FCC Class A
ƒ EMS:- EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
Shock IEC 60068-2-27
Freefall IEC 60068-2-32
Vibration IEC 60068-2-6

The EKI-2525 supports a Fast Ethernet solution. The power is a 12 ~ 48 VDC redundant input design, and is secured with a double protection mechanism: Power Polarity Reverse Protect and an Overload Current Resettable Fuse. The former tolerates reverse power wiring while the latter secures the system from overload currents. As the power supply turns normal, EKI-2525 will automatically get back to work. Each port of EKI-2525 has 2 LEDs to show the link status transmission speed and collision status. It also provides a relay output for an event alarm. In the event of a power failure, the built-in LED will activate the alarm to notify administrators.
